SeaStar CCX633 XTREME Premium Control Cables Black

The CCX633 XTREME Premium Control Cables Black
feature XTREME’s innovative unique design that incorporates a
patent-pending splined core. The ridges on the core allow a close
fit with the cables inner liner, but with minimum contact, so the
core glides back and forth smoothly like a skater on ice. This
advancement in manufacturing technology has resulted to a control
cable with easy movement and minimum lost motion.

CCX633 XTREME Premium Control Cables Black
Specifications:

• Particularly suited to complex routing and longer runs
• Fits directly into SeaStar Solutions controls and all controls
  that accept universal type cables
• Stainless steel and chrome brass end fittings. 10-32 UNF
  threads
• Nominal 75mm travel
• Flexible multi-strand galvanised steel core with splined
  jacket
• 100mm minimum bend radius
• Parallel lay wire strand reinforced outer jacket for superior
  strength and flexibility
• Suits stern drives, inboards and outboards

CCX633 XTREME Premium Control Cables Black Dimensions
Chart:

CCX633 XTREME Premium Control Cables Black
Diagram:
