A new and cleaner way to connect your VHF antenna
with QuickConnect.
To make it easy and convenient to install, replace or stow away
your antenna, Shakespeare designed the QuickConnect antenna system
with cable attached to the mount instead of the antenna itself.
Versatile four-way ratchet action and fast-release handle design
for quick and easy laydown. For deck or side mounting of
QuickConnect antennas.
Key Features
Features:
- QuickConnect: Easy removal of an antenna
without the hassle of re-installing cables - High quality connection: No noise generated
due to vibrations - Splash protection cap: Protect the connector
on the mount when antenna is disconnected; Stays fastened to mount
to prevent it from getting lost - Warranty: Two year limited warranty
- Centerpin PL-259 Connector: Easy crimp-on type
connector - Thread: 1′-14
- Cable: 20′ of RG-58
- Bolt holes: 9/32 dia. (7.14mm), 3 x 1/2
(76.2mm x 12.7mm) on center - Nylon mount: Handles antennas up to 4′
- Note: To be used with QuickConnect antennas
only
Specifications:
| Name | Value |
|---|---|
| Compatibility | QuickConnect Antennas |
| Dimensions | 6′ Width x 3′ Height x 2′ Depth |
| Mounting Hardware | 4 Screws (Sold Seperately) |
| Material | Nylon |
| Mount Type | Quick Disconnect |
| Type | Ratchet Mounts |
| Warranty Details | Two Years |
| Weight | 24 Ounces |
